| DIGITAL
LUX METER MODEL: LX-101 |
|
|
|
DIGITAL LUX METER
MODEL:LX-101
RANGE:0-50000 LUX
|
|
|
|
FEATURES
|
| * Scnsor used
the exclusive photo diode & color correction
tilter, spectrum meet C.I.E. photopie |
*LSI-circuit
use provides high reliability and durability |
| *Sensor
COS correction Factor meet standard |
*Built-in low
abattery indicator. |
| *Separate
LIGHT SENSOR allows user take measurements of
an optimum position |
*LCD
display provides low power consumption |
| *Compact,light-weight,and
excellent operation |
| *Precise and
easy readout, wide range |
*LCD
display can clearly read out even of high ambient
light. |
| *High accuracy
in measuring |
|
|
|
GENERAL SPECIFICATIONS |
|
| Display |
13 mm (0.5") LCD. |
Power supply |
DC:9Vbattery.006P,
MN1604(PP3) or equivalent. |
| Ranges |
0-50,000 Lux 3 Range |
| Zero adjustment |
Internal adjustment. |
Power
consumption |
Approx
DC 2 mA |
| Over-input |
Indication of " 1 " |
| Sampling time |
0.4 second. |
Dimension |
Main Instrument:108x73x23 mm(4.3x2.9x0.9 inch) |
| Sensor structure |
The exclusive photo diode
&color correction filter. |
| Sensor probe:82x55x7
mm(3.2x2.2x0.3inch) |
| Operation Temp |
0 to
50 ℃(32 to
122℉) |
Operation
Humidity |
Less than 80& R.H. |
Weight |
160g(0.36LB)with batteries |
| Accessories Included |
Instruction manual.....1PC |
| Carrying
case...........1PC |
|
|
|
ELECTRICAL
SPECIFICATIONS (23+/-5℃) |
| Range |
Resolution |
Accuracy |
| 2,000 Lux |
1 Lux |
+/- (5%+2d) |
| 20,000 Lux |
10 Lux |
+/- (5%+2d) |
| 50,000 Lux |
100 Lux |
+/- (5%+2d) |
| Note: Accuracy tested by a standard parallel light tungsten
lamp of 2856∘K temperature |
|
|
| DIGITAL
LIGHT METER Model: LX-102 |
|
|
|
DIGITAL LIGHT METER
MODEL:LX-102
RANGE:0-50000 LU
0-5000 FT-CANDLE
|
|
|
|
|
|
|
FEATURES
|
| * Scnsor used
the exclusive photo diode & color correction
tilter, spectrum meet C.I.E. photopie |
*LSI-circuit
use provides high reliability and durability |
| *Sensor
COS correction Factor meet standard |
*Built-in low
abattery indicator. |
| *Separate
LIGHT SENSOR allows user take measurements of
an optimum position |
*LCD
display provides low power consumption |
| *Compact,light-weight,and
excellent operation |
| *Precise and
easy readout, wide range |
*LCD
display can clearly read out even of high ambient
light. |
| *High accuracy
in measuring |
|
|
|
GENERAL
SPECIFICATIONS |
| Display |
13 mm(0.5")
LCD |
Power
Consumption |
Approx.
DC 2mA |
| Measurement |
Lux,
Ft-candle, Data hold, Analog output |
| Output |
Analog output |
| Ranges |
Lux:0 to 50,000 Lux,
3 ranges |
Operation Temp. |
0 to
50℃(32 to 122℉) |
Operation
Humidity |
Less than 80% R.H. |
| Ft-candle:0
to 50000 Ft-cnadle:3 ranges |
| Dimension |
Main
Instrument:163x70x30 mm(6.4x2.8x1.2inch) |
| Zero adjustment |
Internal
adjustment |
| Over-input |
Indication of
"1" |
sensor probe: 82x55x7
mm(3.2x2.2x0.3inch) |
| Sampling time |
Approx 0.4
second |
| Sensor
structure |
The
exclusive photo diode & color correction filter. |
Weight |
220g(0.52LB)with
batteries. |
| Accessories Included |
Instruction manual.......1PC |
| Power Supply |
DC 9v battery.
006P, MN1604(PP3)or equivalent. |
|
|
|
|
ELECTRICAL
SPECIFICATIONS (23+/-5℃) |
| Range |
Resolution |
Accuracy |
Range |
Resolution |
Accuracy |
| 2,000 Lux |
1 Lux |
+/-(5%+2d) |
200Ft-candle |
0.1 Ft-candle |
+/-(5%+2d) |
| 20,000 Lux |
10 Lux |
+/-(5%+2d) |
2000Ft-candle |
1
Ft-candle |
+/-(5%+2d) |
| 50,000 Lux |
100 Lux |
+/-(5%+2d) |
5000Ft-candle |
10 Ft-candle |
+/-(5%+2d) |
|
|
|
|
ANALOG OUTPUT |
| 0.1
mV/1 digit, Max 200.0 mV. |
|
|
|
